Re: Zforce 800 Cage Chop
« Reply #15 on: February 21, 2017, 06:21:29 AM »
Here is a quick video to explain where to cut to chop the factory cage.
t=5s
I can imagine a world completely at peace.  A world where there are no weapons, no war, and no violence at all.  And I can imagine us taking over that world because they would never expect it.

*

Offline autorvshop

Re: Zforce 800 Cage Chop
« Reply #16 on: February 21, 2017, 06:38:20 AM »
COULD YPU PUT UP SOME PICTURES OF HOW YOU BUILT YOUR BACK BONES, IT LOOKS LIKE YOU BOLTED THEM TO THE CAGE, THANSK A LOT, GOOD JOB ON VIDIE FOR OTHERS, ON MY REAR GUSSET I ENDED UP BEING 2 1/4 INCHS ALSO I PUT 2 INSTAED OF THE ONE IN THE CENTER, THANKS
2015 Z800 EX
IRON BALISTIC SKID PLATES
4600 LB WINCH  HOMEMADE BACKBONES
SUPER ATV FULL TILT WINDSHIELD
DUAL BATTERYS   CUSTOM AIR FILTER RELOCATION
42 IN LIGHT BAR, PLUS 4IN SPOTS
TWO BROTHERS EXHAUST
TWIN AIR FILTER
HOME MADE DOORS
TUSK INSIDE ROOF PACK
DOUGLAS MOAPA RUN FLAT TIRES 28  10 FT 12 REAR DOUGLAS STEALTH 8 IN WHEELS FRT, 10 IN WHEELS REAR
QUICK DISCONNECT FIRE EXT
RACKBOSS RACK AND PINION WITH UPGRADED TIRE RODS AND ENDS
EJK TUNER
PRO ARMOR 5 POINT BELTS
18 GRAM SELF MODIFIED DR. PULLEY SLIDERS
SECONDARY CLOCKED TO C2
RIVAL FRT AND REAR BUMPERS
MR RPM OIL FILTER ADAPTER

*

Offline chuddly

Re: Zforce 800 Cage Chop
« Reply #17 on: February 21, 2017, 07:17:55 AM »
Are you talking about the braces that go from the rear bumper to the cage?  Those are just bolted because they (and the rear bumper) are aluminum and cant be welded to steel (roll cage)
I can imagine a world completely at peace.  A world where there are no weapons, no war, and no violence at all.  And I can imagine us taking over that world because they would never expect it.

*

Offline Sockman

Re: Zforce 800 Cage Chop
« Reply #18 on: February 21, 2017, 08:47:41 AM »
Nice work and thanks for posting the video.  Quick question - obviously you test fit the hard top back on after the chop.  Do you lose any rear visibility?
2017 Zforce 800 EX
UNI filter, SuperATV high clearance a-arms, half windshield, rear windshield, custom overhead storage, Grim Reapers

*

Offline chuddly

Re: Zforce 800 Cage Chop
« Reply #19 on: February 21, 2017, 08:54:11 AM »
Yeah you lose some but i plan on cutting my roof to line up with the cage brace bar so it will end up not losing any when I am done
I can imagine a world completely at peace.  A world where there are no weapons, no war, and no violence at all.  And I can imagine us taking over that world because they would never expect it.

*

Online NMKawierider

Re: Zforce 800 Cage Chop
« Reply #20 on: February 21, 2017, 09:27:02 AM »
Thanks for the Vid Chuddly. I was thinking there needed to be some bend somewhere to let it drop but I guess not. And you just butt-welded the cuts?
2015 Z Force 800 (53") EPS -
Custom Air Intakes | Custom Exhaust Mod | SuperATV Harness | Custom Fenders | Custom Skid/Rock Sliders | 27" GBC Grim Reapers | Seizmik Mirrors |Конструктор (Rodin's) Doors | Dr Pulley Sliders | 1.5" Wheel Spacers | BENZ Silencer (as needed) | SATV Flip Windshield W\ Rear Shield | Dual Light Bars | Diamond Plate Storage | Magellan TRX7 GPS| Bandit Springs

My Videos On YouTube

*

Offline locknload

Re: Zforce 800 Cage Chop
« Reply #21 on: February 21, 2017, 09:57:07 AM »
Great job! is there a chance you could set the roof on and take a pic to get an idea
how it looks.
2015 zforce 800 EPS
Super atv flip up windshield
Rodins doors
24" light bar
Special built seat for my dog

*

Offline chuddly

Re: Zforce 800 Cage Chop
« Reply #22 on: February 21, 2017, 12:42:37 PM »
I sleaved all of the cuts and welded them in.  That gives more strength to the cage.

I will try to set my roof on tonight to show you how it sits.  Im not going to bolt it down though because Im going to paint my cage to mach some other parts that are coming and i dont want to pull the roof off again when it shows up.
I can imagine a world completely at peace.  A world where there are no weapons, no war, and no violence at all.  And I can imagine us taking over that world because they would never expect it.

*

Offline WalkinTarget

Re: Zforce 800 Cage Chop
« Reply #23 on: February 21, 2017, 01:01:34 PM »
I just love how this thing has come from a wrecked salvage purchase to a highly modded (and not done yet !!) ready to race SxS. As has already been expressed numerous times, VERY nice job, Chud !! You can chop on my ride any day of the week. It's amazing what a simple chop can do to the look of this thing. It resembles a Maverick X3 from the front with its cage to body ratio closer together. Waiting to hear what you come up with next.
2014 Arctic Cat Wildcat Trail - 27" GBC Dirt Commanders, soft top, quarter windshield, AC front and rear steel bumpers, Bandit springs, EZ Ryde Midnight Edition exhaust, Plano 1719 storage box, Speedwerx throttle and secondary clutch spring, heated seats, Polaris seat slider.

Sold: 2006 King Quad 700 - 27" ITP 589 M/S tires, ITP rims

*

Offline chuddly

Re: Zforce 800 Cage Chop
« Reply #24 on: February 21, 2017, 01:14:29 PM »
Im full of tricks LOL stay tuned to see what crazy adventures I get into next LOL.  Thanks guys.  I enjoy doing it thats for sure.
I can imagine a world completely at peace.  A world where there are no weapons, no war, and no violence at all.  And I can imagine us taking over that world because they would never expect it.

*

Offline ADKMOTO

Re: Zforce 800 Cage Chop
« Reply #25 on: February 25, 2017, 04:05:30 PM »
I sure do wish I could weld better than I do!!! I've wanted to do this since I brought it home from the dealer. Great work, sir!

*

Offline locknload

Re: Zforce 800 Cage Chop
« Reply #26 on: February 27, 2017, 06:45:32 PM »
Have ya had a chance to set the roof on and take a pic, my wife wont
let me do the chop until she sees what it will look like.
2015 zforce 800 EPS
Super atv flip up windshield
Rodins doors
24" light bar
Special built seat for my dog

*

Online NMKawierider

Re: Zforce 800 Cage Chop
« Reply #27 on: February 27, 2017, 06:57:48 PM »
Have ya had a chance to set the roof on and take a pic, my wife wont
let me do the chop until she sees what it will look like.

There's a guy on the CF Moto Owners FB page that took 5"s out of the back of his and put the top back on. Here is one of his pics:

2015 Z Force 800 (53") EPS -
Custom Air Intakes | Custom Exhaust Mod | SuperATV Harness | Custom Fenders | Custom Skid/Rock Sliders | 27" GBC Grim Reapers | Seizmik Mirrors |Конструктор (Rodin's) Doors | Dr Pulley Sliders | 1.5" Wheel Spacers | BENZ Silencer (as needed) | SATV Flip Windshield W\ Rear Shield | Dual Light Bars | Diamond Plate Storage | Magellan TRX7 GPS| Bandit Springs

My Videos On YouTube

*

Offline locknload

Re: Zforce 800 Cage Chop
« Reply #28 on: February 27, 2017, 09:56:39 PM »
Wow that does look a lot better, thanks!
2015 zforce 800 EPS
Super atv flip up windshield
Rodins doors
24" light bar
Special built seat for my dog

*

Online NMKawierider

Re: Zforce 800 Cage Chop
« Reply #29 on: February 27, 2017, 10:53:08 PM »
Wow that does look a lot better, thanks!
Agreed. Mine's going to get this ...."adjustment"...soon.
