Re: Additional Air Cleaner
« Reply #60 on: March 29, 2017, 11:02:49 PM »
I would like to do this improve , But I a little confuse for all the opinions , NMK could you please tell me if this improve is the best for maintain clean the filter , or there are another  new option.
My riding conditions is 90% dust but what happens if raining in the middle of mountains or desert .
Could you please tell me if the purple mushroom is the best for my conditions . Or a I need to buy another thing like the red cap ?
My secondary is in B2 and 24 g .
And I buy today a unifilter because I was with the stock one .
Thanks
First, get that Unifilter in the box. Then, get the end ported outside. Then..well for me after all the filters I tried on it, I ended up putting another Unifilter on the end and covered it with an Outerwear water resistant profiler so the rain will roll off when in the mountains.
2015 Z Force 800 (53") EPS -
Custom Air Intakes | Custom Exhaust Mod | SuperATV Harness | Custom Fenders | Custom Skid/Rock Sliders | 27" GBC Grim Reapers | Seizmik Mirrors |Конструктор (Rodin's) Doors | Dr Pulley Sliders | 1.5" Wheel Spacers | BENZ Silencer (as needed) | SATV Flip Windshield W\ Rear Shield | Dual Light Bars | Diamond Plate Storage | Magellan TRX7 GPS| Bandit Springs

My Videos On YouTube

*

Offline Coloradocrawler

Re: Additional Air Cleaner
« Reply #61 on: May 24, 2017, 10:14:50 PM »
NMK..... I too have done this mod. I used a spectra filter I purchased from AutoZone. I was wondering if you had noticed how loud the intake became after this mod. It sounds pretty throaty when under full throttle. I don't mind it but the wife does. I am now in the process of making a rear window with a vinyl lower curtain to block some of the sound.
2014 Zforce 600
Da-bomb half windshield, Cage chopped 5 1/2 inches, Snorkels for both CVT and Air intake, UNI and Twin-air filters, UE Boom speakers (pair), bed storage (dust proof), GPS (roll bar mount), overhead storage bags, 30 in LED light, Rock lights, Desert Molding Concepts seat springs, C1 clutch setting, 23g Dr. Pulley sliders, scap doors, 28 in Bighorn 2.0's. Fox shocks from a wildcat trail.

*

Offline NMKawierider

Re: Additional Air Cleaner
« Reply #62 on: May 24, 2017, 10:25:17 PM »
NMK..... I too have done this mod. I used a spectra filter I purchased from AutoZone. I was wondering if you had noticed how loud the intake became after this mod. It sounds pretty throaty when under full throttle. I don't mind it but the wife does. I am now in the process of making a rear window with a vinyl lower curtain to block some of the sound.
Sense this I have changed things and now have a different pipe and filters but yeah, while I had this design I tried several different filters and some were louder then others. The pleated microfiber mostly and the mushroom with the single course foam material.   I did find that after I put my monster Unifilter in the box, I didn't hear that intake sound any more.. then added a read shield and another large Uni in the top..don't even think about it anymore.
2015 Z Force 800 (53") EPS -
Custom Air Intakes | Custom Exhaust Mod | SuperATV Harness | Custom Fenders | Custom Skid/Rock Sliders | 27" GBC Grim Reapers | Seizmik Mirrors |Конструктор (Rodin's) Doors | Dr Pulley Sliders | 1.5" Wheel Spacers | BENZ Silencer (as needed) | SATV Flip Windshield W\ Rear Shield | Dual Light Bars | Diamond Plate Storage | Magellan TRX7 GPS| Bandit Springs

My Videos On YouTube

*

Offline Coloradocrawler

Re: Additional Air Cleaner
« Reply #63 on: May 25, 2017, 01:13:23 AM »
NMK..... Do you have any pics of your current set up?
2014 Zforce 600
Da-bomb half windshield, Cage chopped 5 1/2 inches, Snorkels for both CVT and Air intake, UNI and Twin-air filters, UE Boom speakers (pair), bed storage (dust proof), GPS (roll bar mount), overhead storage bags, 30 in LED light, Rock lights, Desert Molding Concepts seat springs, C1 clutch setting, 23g Dr. Pulley sliders, scap doors, 28 in Bighorn 2.0's. Fox shocks from a wildcat trail.

*

Offline NMKawierider

Re: Additional Air Cleaner
« Reply #64 on: May 25, 2017, 09:21:30 AM »
NMK..... Do you have any pics of your current set up?
I think there is a write-up on the new intake tube in the How Toos but lets see...

This is the 5X8"(10"s total) Unifilter in the box now:



This is of the new 2.5" tube with the 2.5" to 3" silicone 90 at the top:



And I think this is the only photo I have of the top 5X6" Uni on top. It has the Outerwears prefilter on it. I have sense installed a bracket on the box for the end to set on as it was tending to hang down in time because of it's weight:



And one showing the CVT intake air filter which is a dual-cone, 6", dry-type microfiber with another prefilter over it. This makes it easy to just wash with water or blow-out and slap it back on:



Both filter intakes are 3" so I can use either on..either and also the spare I carry in the trunk will go on either if necessary.

I would also like to add that...If I had it to do all over again, I think I would have leaned more toward having this stuff higher...like maybe on snorkels or some kind of box-system mounted higher...still with filters, just not trapped down low like they are as it gets pretty dusty and wet back there at times. And I picked and mounted my box so I could drop a 4-gal flat pac back there and now...I can't....but if I through the mushroom filter back on..which I can...I think I can get the pac in there even with the other filter there. Guess I should try.
